Thermoforming Machines

A thermoforming machine makes the pack as part of the process, heating flat film into a tray or cavity before the product is filled and the pack is closed. Because the tooling sets the shape, the format follows the mould rather than whatever a tray supplier holds in stock.

Thermoforming Machines for Food, Medical and Consumer Goods

Forming, filling, sealing and cutting run in sequence on one frame, so the pack is produced and closed without being handled between stages. ILPRA UK supplies thermoformers from compact entry-level machines through to automatic systems that integrate with dosing and loading equipment as part of a complete line.

How the Thermoforming Process Works

The machine works through a fixed cycle, with film indexed forward one step at a time:

  • Heating: Flat bottom film is warmed until it becomes pliable.
  • Forming: The softened film is drawn into the mould cavity to create the pack.
  • Filling: Product is loaded into the formed cavity, by hand or from upstream equipment.
  • Sealing: Top film is applied and sealed across the cavity, with the atmosphere inside the pack set at this stage.
  • Cutting: Linear and perimetric cuts separate the formed strip into individual packs.
  • Discharge: Finished packs leave the frame for coding, inspection or secondary packaging.

Step length sets how far the film advances each cycle and therefore the pack length available. That ranges from 300mm on the entry-level FormPack machines to 1100mm on the VKF90.

Forming Modes

All the machines in the range can be configured for four pack types, which is what makes thermoforming workable across quite different products:

  • Sealing: A standard sealed pack, with the top film closed across the formed cavity.
  • MAP: The air in the pack is replaced with a gas mixture before sealing.
  • Vacuum: Air is drawn out of the pack before the seal is made.
  • Skin: The top film is drawn down onto the product itself, holding it against the base of the pack. The VKF90 can run skin with or without an edge.

Which of these you need is usually settled by the product and its shelf life rather than by output, so it is worth confirming before tooling is specified.

Choosing a Thermoformer

FormPack and VKF machines run the same forming modes but suit different scales of production. The compact FormPack range is a natural starting point for producers moving into formed packs or running moderate volumes in limited space, while the automatic VKF range is built for continuous production, deeper packs and integration into a complete line.

Thermoforming is often compared against tray sealing and the pack usually the deciding factor. Tray sealing needs no tooling but limits you to trays you can buy, while thermoforming makes the pack on the line, giving control over shape and presentation and removing tray costs in exchange for tooling for each format.
